TDPRO JCMOTO 24v 350w Brushed Speed Motor and Controller Set for Electric Scooter Go Kart Bicycle e Bike Tricycle Moped
Product details
| Management number | 216712359 | Release Date | 2026/04/19 | List Price | US$32.00 | Model Number | 216712359 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specifications:Motor:Output: 350WRated speed: 2650-2950 RPMRated voltage: 24V DCRated current: 19.1ANo-load current: ≤2.2APeak efficiency at 24V: 80 percentReversible: (w/ polarity swap)Sprocket：11 tooth sprocket for #25H chainNote: This motor is capable of rotation in either the clockwise or counterclockwise direction by reversing the motor's power wires.Controller:Rated voltage: 24V DCConversion efficency: 95% Under Voltage Protection: 20±0.5VSpeed regulator (throttle): 1-4 VController Wiring:This controller has 8 connectors, compatible with many 24V bikes with up to 350W motors1. Battery / 2. Motor / 3. Brake / 4. Brake light / 5. Indicator light / 6. Ignition lock / 7. Charger port / 8. Derailleur (throttle)These controllers have 4 groups neccessary cables: Battery, Motor, Ignition lock, Derailleur (throttle), when hook up these 4 groups cables, the E-bike can run normally. Besides, this controller have other optional functions, you can hook them up according to your applications.
- √ This is a set of reliable universal 24VDC 350w brushed electric motor & controller
- √ Rated speed: 2750 RPM, Sprocket：11 tooth sprocket for #25H chain, Horsepower: 0.48HP
- √ Suitable for go karts, scooters, e-bike, atv, motorized bicycle, moped, mini bikes, pocket bikes and electric dirt bikes
- √ Refer to picture and below "Product Description" for wiring instruction and specifications
- √ Package includes: 1x Motor + 1x Controller
| UPC | 611677060251 |
|---|---|
| Size | 24V 350W |
| Color | Black |
| Theme | Electric Vehicles |
| Wattage | 350 watts |
| Bike Type | Electric Bike |
| Brand Name | TDPRO |
| Style Name | Hybrid |
| Wheel Size | 6 Inches |
| Manufacturer | TDPRO |
| Power Source | battery |
| Is Autographed | No |
| Wheel Material | Alloy Steel |
| Number Of Speeds | 3 |
| Additional Features | Electric |
| Frame Material Type | Aluminum |
| Included Components | Lock |
| Is Assembly Required | No |
| Age Range Description | Adult |
| Bicycle Gear Shifter Type | Twist Grip |
| Specific Uses For Product | Multi-purpose |
